The gas and liquid mixer flow pump is a fluid transfer product specially developed for electrochemical testing applications.
- This pump is primarily used on the anode side to rapidly remove large volumes of bubbles generated during anode side experiments.
- Compatible with 3 mm PTFE tubing.
- When paired with quick connect fittings, the pump generates unique shear force to quickly disperse gas into fine mist, which is then carried away by the liquid.
See figure below.
- Flow Rate Range: 140 ml‑170 ml/min (Automatic adjustment)
(Maximum flow 320mL/min.)
- Operating Pressure: 90 kPa
- Power Supply: AC 220V
- Rated Voltage: AC 24V
- Load Current: 150 mA
- Overall Dimensions: 145 × 95 × 90 mm
- Weight: 1.5 kg
- Joint size : 1/8"
